What is the blow-up ratio in a film blowing machine?

Are you finding it hard to get consistent film quality from your machine? This can lead to wasted materials and unhappy clients. Understanding the blow-up ratio (BUR)¹ is key to solving this problem.

The blow-up ratio (BUR) in a film blowing machine is the ratio of the final diameter of the inflated film bubble to the original diameter of the circular die. This ratio tells us how much the plastic expands after exiting the die.

This number is very important in our work at BagMec®. The BUR directly shapes the film's internal structure. This structure affects how strong, clear, and protective the film is. Getting the BUR right helps us make top-quality film every time. Our machines are built to give you precise control over this ratio. We know that careful adjustment here makes a big difference in the final bag product.

For example, if we increase the BUR, the film usually stretches more side-to-side. This can make the film harder to tear in that direction. But, if we make the BUR too high, the film might get too thin or unstable. On the other hand, a lower BUR can make a thicker film with different strength characteristics. We help our BagMec® customers find the ideal BUR for their specific needs. This ensures their bags perform well.

Why is understanding the Blow-Up Ratio crucial for film quality?

You might know what BUR is now. But why is it so vital for your film? Let's look at how BUR really affects your final product.

Understanding BUR is crucial because it directly controls the film's mechanical properties². These include tensile strength, tear resistance, and impact strength, which are vital for the film's performance and suitability for its intended use.

The Nitty-Gritty of BUR and Film Properties

At BagMec®, we've seen firsthand how BUR influences various aspects of the film. It's not just about how much the film expands; it's about the quality that expansion creates.

Impact on Molecular Orientation

When we blow the film, the plastic molecules inside the film get stretched and aligned. The BUR plays a big role in how these molecules line up.

• A higher BUR tends to stretch the molecules more in the transverse direction (TD), which is across the film web.
• A lower BUR might lead to more orientation in the machine direction (MD), which is along the film web.
• A balanced orientation between MD and TD often gives the best overall strength. Our machines, like those for food-grade packaging, are designed to help achieve this balance for optimal barrier properties. We've seen this help clients like a German packaging supplier reduce material waste by ensuring film integrity.

Correlation with Film Thickness and Consistency

The BUR also affects how even the film thickness³ is.

• If the BUR is not set correctly for the material or process conditions, you can get thick and thin spots. This is known as gauge variation.
• Inconsistent thickness not only wastes plastic but also makes the bags weaker in the thin spots.
• Our BagMec® machines, especially those with "Smart Tension Control," help maintain a stable bubble. This stability is key to achieving uniform thickness and a consistent BUR profile.

Influence on Optical Properties

For many bags, especially food packaging or retail bags, how the film looks is important.

• The BUR can change the film's clarity and gloss.
• A well-controlled BUR, matched with the right cooling, can produce clearer, shinier film.
• For example, in our Lamination Pouch Making Machines, precise BUR control is essential for the optical quality of the final multi-layer pouch.

How do you accurately calculate and control the Blow-Up Ratio?

Knowing BUR is important is one thing. But how do you measure and manage it? Let's look at the practical side.

You calculate BUR by dividing the final bubble diameter (or the layflat width of the collapsed tube multiplied by 2/π) by the die diameter. Control is achieved by adjusting air volume into the bubble, take-up speed, and melt temperature, often managed by our machine's PLC systems.

Mastering BUR Calculation and Control

Calculating and controlling BUR is a core part of operating a film blowing line. We make our BagMec® machines to give operators the tools they need.

The Calculation Explained

The formula for BUR is straightforward:

BUR = Final Bubble Diameter (D_f) / Die Diameter (D_d)

If you measure the layflat width (L_fw) of the collapsed film tube instead of the bubble diameter, the formula is:

BUR = (L_fw × 2/π) / D_d
(Where π is approximately 3.14159)

Let's break down where these numbers come from:

Component	Symbol	How to Get It
Final Bubble Diameter	Df	Measure the diameter of the stable, inflated bubble.
Layflat Width	Lfw	Measure the width of the film after it's collapsed.
Die Diameter	Dd	This is a fixed specification of your machine's die.

For instance, if your die diameter is 100 mm and your final bubble diameter is 250 mm, your BUR is 250/100 = 2.5:1.

Key Control Parameters in BagMec® Machines

Controlling BUR involves a few key adjustments on the machine:

• Internal Air Pressure/Volume: This is the main way to control the bubble size. More air generally means a larger bubble and higher BUR. Our machines have precise air regulation.
• Take-Up Speed: The speed at which the nip rollers pull the film upwards. Changing this affects film thickness, which can interact with bubble stability and thus the manageable BUR.
• Melt Temperature: The temperature of the plastic as it leaves the die. Hotter melt is usually easier to stretch, potentially allowing a higher BUR. Our systems ensure stable temperature.
• Cooling: Efficient air cooling from the air ring stabilizes the bubble shape quickly. BagMec® focuses on advanced air ring designs.
• Extruder Output: The amount of plastic being pushed through the die. This must be balanced with take-up speed for desired thickness.

Our BagMec® machines, equipped with PLC controls and touchscreen interfaces, allow operators to fine-tune these settings. Features like our patented "Smart Tension Control" help maintain consistent film feeding, which supports stable bubble formation and BUR.

What are the optimal Blow-Up Ratios for different film types and applications?

There isn't one perfect BUR for every situation. Different plastic materials and bag types need different BUR settings. Let's explore some common examples.

Optimal BURs vary: LDPE films for shopping bags often use 2:1 to 4:1. HDPE films might use lower BURs like 1.5:1 to 3:1 for better stiffness. Specialty films like those for lamination will have specific BUR needs for layer integrity and strength.

Matching BUR to Film Needs

At BagMec®, we help our customers find the sweet spot for BUR based on the bags they're making. Here are some general guidelines:

Low-Density Polyethylene (LDPE) Films

• Applications: Shopping bags (like those from our Loop Handle Bag Making Machine or T-Shirt Bag Making Machine), food packaging, general purpose films.
• Typical BUR Range: 2.0:1 to 4.0:1.
• Reasoning: LDPE has good melt strength, allowing it to be blown to higher ratios. A higher BUR can improve clarity and balance MD/TD tear strength. For our Food Package Bag Machines, this range is common.

High-Density Polyethylene (HDPE) Films

• Applications: Thinner T-shirt bags, produce bags, some liner bags.
• Typical BUR Range: 1.5:1 to 3.0:1, sometimes up to 4:1 or 5:1 for very thin films (HMW-HDPE).
• Reasoning: HDPE is stiffer. Lower BURs can enhance its stiffness and MD tensile strength. Our T-Shirt Bag Making Machines are designed to handle HDPE effectively.

Linear Low-Density Polyethylene (LLDPE) Films

• Applications: Heavy-duty bags (from our Heavy Duty Bag Machine), stretch film, agricultural film.
• Typical BUR Range: 2.0:1 to 3.5:1.
• Reasoning: LLDPE offers excellent puncture and tear resistance. The BUR influences the balance of these properties. For instance, our Courier Bag Machines use LLDPE blends optimized for toughness.

Polypropylene (PP) Films

• Applications: Clear packaging, textile bags, some food packaging.
• Typical BUR Range: 2.5:1 to 5.0:1 (for blown PP, which is less common than cast PP).
• Reasoning: PP can be very clear when processed correctly. BUR affects its orientation and clarity.

Biodegradable Films (e.g., PLA)

• Applications: Compostable shopping bags, organic waste bags.
• Typical BUR Range: Often lower, around 1.5:1 to 2.5:1.
• Reasoning: PLA and other bioplastics can have lower melt strength than traditional polyolefins. This makes them more challenging to blow to high ratios. We co-developed machines for a US Eco-Brand making 100% compostable PLA shopping bags, carefully optimizing BUR.

Quick Reference Table: Typical BURs

Material	Common Application	Typical BUR	BagMec® Machine Example
LDPE	Shopping Bags, Food Bags	2.0:1 - 4.0:1	Loop Handle Bag Machine, Food package bag machine
HDPE	T-Shirt Bags, Liners	1.5:1 - 3.0:1	T-Shirt Bag Making Machine
LLDPE	Heavy Duty Bags, Courier Bags	2.0:1 - 3.5:1	Heavy Duty Bag Machine, Courier bag machine
PLA	Compostable Bags	1.5:1 - 2.5:1	Customized machines (like for US Eco-Brand)

Remember, these are general guidelines. The exact optimal BUR will also depend on your specific resin grade, additives, and desired film properties.

How do BagMec® machines help achieve precise Blow-Up Ratios?

Opening Paragraph for h2: Knowing about BUR is good. Having a machine that helps you control it precisely is better. Let's see how BagMec® machines make a difference.

BagMec® machines help achieve precise BUR through advanced die and air ring designs, our "Smart Tension Control" system for stable film feeding, precise temperature management, and intuitive PLC systems. These features ensure consistent bubble formation and easier BUR control.

BagMec® Technology for Optimal BUR

We at BagMec® build our machines with features specifically designed to give you fine control over the film blowing process, including the BUR.

Precision Engineered Dies and Air Rings

The heart of BUR control starts at the die and air ring.

• Die Quality: Our dies are manufactured with high precision at our Wenzhou facility (ISO 9001 certified). This ensures a uniform flow of molten plastic, which is the first step to a stable bubble.
• Air Ring Design: We use advanced air ring designs. These provide consistent and high-velocity airflow to cool and stabilize the bubble quickly. A stable bubble is essential for maintaining the target BUR and film thickness. This is critical for all our machines, from the Side Sealing Bag Machine to the complex Wicketer Bread Bag Machine.

"Smart Tension Control" and Servo Motors

Consistent film handling is key to a stable bubble.

• "Smart Tension Control": This patented BagMec® technology ensures that the film is pulled away from the die at a very consistent rate. Fluctuations in tension can destabilize the bubble, affecting the BUR. Our system minimizes this.
• Energy-Saving Servo Motors: We use servo motors for key drives, like the take-up rollers. These motors offer very precise speed control, which is crucial for maintaining film thickness and, indirectly, the BUR. As a bonus, they reduce power consumption by up to 30%.

Advanced Automation and Control Systems

Ease of use and repeatability are important for consistent production.

• PLC Control with Touchscreen: Most BagMec® machines feature Programmable Logic Controllers (PLCs) with user-friendly touchscreen interfaces. This allows operators to easily set and adjust parameters like air flow, take-up speed, and extruder speed, all of which influence the BUR.
• Recipe Management: Many of our fully automated systems allow operators to save and recall "recipes" for different film types and bag specifications. This means you can quickly set up the machine to achieve the desired BUR for a specific product. This is a feature our client, a German packaging supplier using our FFS bag machines, appreciates for achieving 99% uptime.

Material Versatility and Customization

We understand that different materials behave differently.

• Wide Material Compatibility: Our machines are designed to handle various materials, including LDPE, HDPE, PP, biodegradable PLA, and multi-layer laminates. We consider the unique melt characteristics of each when designing the machine components that affect BUR.
• Custom Solutions: For unique applications, like the biodegradable PLA film machines for the US Eco-Brand, we offer customized solutions. This includes optimizing the die, screw, and cooling systems to handle the specific material and achieve the target BUR for 100% compostable bags.

By combining these technological features, BagMec® machines provide a stable and controllable platform for achieving the precise Blow-Up Ratio your film products require.

Conclusion

Understanding and controlling the blow-up ratio is vital for high-quality film production. It impacts film strength, clarity, and consistency. BagMec® machines are engineered to give you the precision needed to master BUR for superior bag making.

---
